Model E 110 Sub A

Product Class Elements

Frequency response -10 dB 45 Hz – 150 Hz, via the active system crossover

subwoofer amplifier 1x 600 W / Class D @ 4 ohms

Active protectiion circuits RMS limiter, subsonic filter, 2 system filters, depending on the number of connected mid/ high units

Connections 1 Combination XLR 1/4” In, 1 XLR Out, Speakon Parallel Out, 2 E-Connect Outs

LF Speaker 1x 10"

Pole mount 2 E-Connect sleeves

Dimensions (WxHxD) 30 x 48 x 46 cm • 11-13/16 x 18-7/8 x 18-1/8"

Weight 19 kg / 41,9 lbs.
