Dimensions

Width

1461mm (57-1/2") (Polished finish: 1466mm (57-11/16"))

Height

927mm (36-1/2") (Polished finish: 930mm (36-5/8"))

Depth

459mm (18-1/16") (Polished finish: 459mm (18-1/16"))

Weight

Weight

58.0kg (127lbs., 14oz) (Polished finish: 61.5kg (135lbs., 9oz))

Keyboard

Number of Keys

88

Type

GH3X (Graded Hammer 3X) keyboard with synthetic ivory keytops, escapement

Touch Sensitivity

Hard 2, Hard 1, Medium, Soft 1, Soft 2, Fixed

Pedal

Number of Pedals

3

Half Pedal

Yes

Functions

Damper with half pedal effect, Sostenuto, Soft

Display

Type

Full Dot LCD

Panel

Language

English

Key Cover

Key Cover Style

Sliding

Music Rest

Yes

Tone Generation

Piano Sound

Yamaha CFX, Bösendorfer Imperial

Key-off Samples

Yes

String Resonance

Yes

Smooth Release

Yes

Damper Resonance

Yes

Polyphony

Number of Polyphony (Max.)

256

Preset

Number of Voices

34

Types

Reverb

6

Chorus

3

Brilliance

7

Master Effect

12

Intelligent Acoustic Control (IAC)

Yes

Functions

Dual/Layers

Yes

Split

Yes

Preset

Number of Preset Songs

18 (Voice Demo), 50 (Piano), 303 (Lesson)

Recording

Number of Songs

250

Number of Tracks

16

USB Audio Recorder

Playback

WAV

Recording

WAV

Metronome

Tempo Range

5～500 (quarter note)

Overall Controls

Transpose

Yes

Other Control

Tuning, Scale Type, etc.

Storage

Internal Memory

approx. 1.5MB

External Drives

USB Flash Memory

Connectivity

Headphones

2

MIDI

IN, OUT, THRU

AUX IN

Stereo Mini

AUX OUT

L / L+R, R

USB TO DEVICE

Yes

USB TO HOST

Yes

Amplifiers

30W x 2

Speakers

16cm x 2 [6-5/16" x 2]

Acoustic Optimizer

Yes

Power Consumption

20W

Accessories

Headphones Hanger, "50 greats for the Piano"
