מוניטור אולפני בודד
Inputs
|
|
|
1- Stereo 1/8" |
1- Balanced XLR |
1- Balanced XLR |
|
|
2- Balanced ¼” TRS |
1- Balanced ¼” TRS |
1- Balanced ¼” TRS |
|
|
2- Unbalanced RCA |
1- Unbalanced RCA |
1- Unbalanced RCA |
Performance
|
|
Frequency Response |
70 Hz - 20 kHz |
53 Hz - 22 kHz |
35 Hz - 22 kHz |
|
Crossover Frequency |
2.8 kHz |
3 kHz |
2.2 kHz |
|
LF Amplifier Power |
25W/speaker |
45W |
75W |
|
HF Amplifier Power |
(not biamped) |
35W |
65W |
|
Peak SPL (@ 1 meter) |
100 dB |
102 dB |
105 dB |
|
LF Driver |
4.5" Kevlar® |
5.25” Kevlar® |
8” Kevlar®
|
|
HF Driver |
1” silk dome
|
1” silk dome |
1.25” silk dome |
|
Input Impedance |
10 kΩ |
10 kΩ |
10 kΩ |
User Controls
|
|
Volume Range |
A-type taper |
A-type taper |
A-type taper |
|
MF Control |
Variable (-6 to +6 dB) |
-6, 0, +6 dB |
-6, 0, +6 dB |
|
HF Control |
Variable (-6 to +6 dB) |
-6, 0, +6 dB |
-6, 0, +6 dB |
|
Low Cut |
Flat, 80 Hz, 100 Hz |
Flat, 80 Hz, 100 Hz |
Flat, 80 Hz, 100 Hz |
|
Acoustic Space |
Flat, -2 dB, -4 dB
|
Flat, -2 dB, -4 dB |
Flat, -2 dB, -4 dB |
Protection
|
|
|
RF interference |
RF interference |
RF interference |
|
|
Output-current limiting |
Output-current limiting |
Output-current limiting |
|
|
Over-temperature |
Over-temperature |
Over-temperature |
|
|
Turn-on/off transient |
Turn-on/off transient |
Turn-on/off transient |
|
|
Subsonic filter |
Subsonic filter |
Subsonic filter |
|
|
External mains fuse |
External mains fuse |
External mains fuse |
Power
|
|
|
100-120V ~50/60 Hz or 220-240V ~50/60 Hz
|
100-120V ~50/60 Hz or 220-240V ~50/60 Hz |
100-120V ~50/60 Hz or 220-240V ~50/60 Hz |
Cabinet
|
|
|
Vinyl-laminated, medium-density fiberboard |
Vinyl-laminated, medium-density fiberboard |
Vinyl-laminated, medium-density fiberboard |
Physical
|
|
Width |
6.42" (163 mm) |
7” (178 mm) |
9.84” (250 mm) |
|
Depth |
7.09" (180 mm) |
7.68” (195 mm) |
11.77” (299 mm) |
|
Height |
9.45" (241 mm) |
10.24” (260 mm) |
15.12” (384 mm) |
|
Weight |
13 lb. (5.9 kg) |
10.2 lbs (4.63 kg) |
22.2 lbs (10.07 kg) |
NOTE: As a commitment to constant improvement, PreSonus Audio Electronics, Inc., reserves the right to change any specification stated herein at any time, without notification.
|
|
|
|
|
|
